Manufacturer:SKU: 2025-03101 |
DURST
5 meter. |
Model:512R Plus w/ White |
Seller’s statement:
“Very good working condition and always properly maintained and serviced. Yes it has white. 6 Color plus white.Mesh Kit.Out feed Vertical Slitters.Double Sided Printing.” |
Year: |
2019 |
Location:USA |
Fast & easy shipping available. |
Extras: |
Owner’s manual. |
Functional: |
Yes. |
Availability: |
 |
Financing & Services:
|
As a courteous suggestion we can offer you very good competitive shipping prices through a few different insured carriers that are responsible for your freight. Also as a courteous suggestion we have access to offer to you great pricing on certified technicians for de-installs, installs, training, service, tech support, consumables, parts, tooling, etc. |
5-meter (200″) width.
UV-curable roll-to-roll printer.
Can process three 1.6 meter rolls at the same time.
Industrial build for unsupervised printing and extremely low production costs.
The Durst Rho 512R is the most productive 5-meter roll-to-roll UV-Curable printer in its class, defining the quality standard for industrial backlit and fine art printing.
It features Durst’s Quadro Array 12M printheads with Variodrop technology. The12 picoliter drop size enables excellent image quality with up to 800 dpi, while the Variodrop technology is responsible for the printer’s high productivity with exceptional image quality.
The 512R offers true lights out unattended printing; with its standard roll-to-roll offering of 660 lbs or optional 1100 lb roll weights you can be assured of reduced labor costs.
- High pigment inks reduce ink consumption and lower cost per square foot
- Over 24,000 nozzles for the highest productivity and image quality
- Can print three rolls of 1.6-meter (5’2?) rolls of media at the same time with individual print queues
- Variodrop technology
- True unattended printing with its standard roll-to-roll offering of 660 lbs or optional 1100 lb roll weights you can be assured of reduced labor costs
- Integrated border cutting
- Partial matte/gloss print mode
- 100% VOC-free, UV-curing Rho pigment ink with Nordic Swan certification and level 8 on the Blue Wool scale for indoor and outdoor applications
- No speed reduction in backlit
| INK TYPE | UV-Curable |
| COLORS | CMYK + Lc, Lm, Process Colors or White (as base coat/overprint and as a color) |
| INK CAPACITY | Integrated ink tank is 10-liter capacity per ink, refillable during the printing process. Refill inks are 5-liter containers |
| WIDTH | 16.4’ (5 m) |
| MEDIA HANDLED | Roll |
| PRINTHEAD TECHNOLOGY | Durst Quadro Array 12M, 12pL |
| HEADS | 24,000 nozzles |
| RESOLUTION | 800 |
| PRODUCTION SPEED
SQ FT SQ M |
2045 190 |
| DIMENSIONS
IN (W x D x H) CM (W x D x H) |
334 x 86.4 x 81.6 847 x 220 x 208 |
| WEIGHT | 16,500 lbs |
| ELECTRICAL REQUIREMENTS | 3 Phase + N 230/400V (10%) / 26kVA 50/60Hz |
| AMBIENT TEMPERATURE | 59º F – 86º F (15ºC – 30ºC) |
| RELATIVE HUMIDITY | 25 – 80% (non-condensing) |
